Technology
Hermle CNC machining center
with 5 simultaneous axes
Travel X 610mm
TravelY 450mm
Travel Z 450mm
Max. Speed 12000 rpm
Rapid traverse in all axes 65 m / min
Chip-to-chip time 5.5s
Record processing time 4ms
Infrared 3D probe for workpiece measurement
NC swivel rotary table C 600 U
Optimal utilization of the work space with the
NC swivel rotary table, which is laterally in the walls
of the machine bed is stored.
Machining in 5 simultaneous axes.
Clamping surface 370 x 370 mm or in 4 axes
with clamping table 600 x 420 mm
Additional applications:
Blum laser tool measurement system for tool length
and diameter (Tol.0.3 & mu;)
Tool breakage / wear monitoring in the program sequence
3-way rotary feedthrough hydr. & Pneum. for fixtures or clamping systems
(EROWA system)
El. Thermal expansion compensation in the Y and Z axes
Firmengeschichte
ZH-Zerspanungstechnik GmbH
was founded in 1998 in a car
garage as a sideline. In 2001 a
production hall was built and
moved into. The first new
machining center was created. In
2002 the first Hermle 5-axis
machine was discontinued and a
complete 5-axis CAD / CAM
workstation was set up.
Since September 2008 we have
moved to a larger production hall
in Stegwiesen 9. Today are
4 Hermle 5-axis machines,
3 machining centers,
1 CNC coordinate measuring
machine,
2 CNC 5-axis machines
4 machining centers
1 laser marking device,
1 CNC band saw machine,
2 ultrasonic cleaning devices
and 2 ELB surface grinding
machines
in action.
At the moment our team consists
of 2 masters, 7 specialists,
an office worker, 3 trainees and
several temporary workers in
production.
